Product Specifications:
| Item | Specification |
| Output Signal | 4–20 mA |
| Measuring Range | −0.1 to 100 MPa |
| Pressure Type | Absolute pressure, Relative pressure |
| Power Supply | DC 12–32 V (5 V and 3.3 V available for voltage-output versions only) |
| Compensated Temperature | −10 to 70 °C |
| Operating Temperature | −40 to 70 °C |
| Response Time | ≤10 ms |
| Storage Temperature | −40 to 125 °C |
| Zero Temperature Drift | ±0.15% FS |
| Span (Sensitivity) Temperature Drift | ±0.15% FS |
| Overpressure | 150% FS |
| Mechanical Vibration | 20 g (20–5000 Hz) |
| Shock Resistance | 100 g (11ms) |
| Overall Accuracy | Standard: ±0.5% FS ,(optional): ±0.2% FS |
| Long-Term Stability | ±0.2% FS/year |
| Insulation Resistance | ≥100 MΩ at 250 V DC |
| Protection Rating | IP65 |
| Material Compatibility | Suitable for various liquids or gases compatible with stainless steel |
